iFlight SucceX Micro F4 V2.1 16×16 Flight Tower System Stack – F411 Pro FC + 200mW VTX + 15A 2-4S ESC

This iFlight Succex Micro Tower System includes the advanced SucceX Micro F4 V2.1 Flight Controller along with the SucceX Micro 15A V2 4-in-1 ESC, which can push your FPV racer to the max!

Specifications

SucceX Micro F4 V2.1 Pro Flight Controller

• STM32F411
• Input voltage 2-4S LIPO
• Gyro: MPU6000
• 2x UART ports
• 4x motor outputs
• Betaflight OSD :AT7456E
• Blackbox FLASH: 8MB
• BEC 5V 2.5A cont.
• Size: 21mm*21mm
• Mounting holes distance: 16*16mm
• Weight: 2.5g
• Firmware : IFF411_PRO(IFRC)

SucceX Micro 15A 4-in-1 ESC(w/plug)

• Firmware: G-H-30 BLS 16.7
• BLHeliSuite: http://www.mediafire.com/file/1tn449x6815upat/BLHeliSuite16714901.zip/file
• ESC protocol: pwm, oneshot125, multishot, dshot150, 300, 600, etc.
• Input voltage : 2-4S LIPO
• Mounting hole 16*16mm
• Continuous current: 15A
• Current sensor: yes
• Size: 30mm*22mm
• MCU: BB21F16G
• Weight: 3.6g
• BEC: NO

5.8G 200mW Micro VTX

• Antenna interface: IPEX (UFL)
• Power: PIT/25/100/200mW
• Mounting holes: 16*16mm
• VTX protocol: IRC Tramp
• Size: 17mm*27mm
• Weight: 1.6g

Downloads

• SucceX Micro 16×16,SucceX Whoop FC Firmware(beta flight 3.5.7)
• SucceX Micro F4 V2.1 Manual

Includes

• 1x SucceX Micro 15A Brushless ESC (w/plugs, M3 hole)
• 1x SucceX Micro F4 V2.1 Flight controller (M3 hole)
• 1x PIT/25/100/200mW VTX (M3 hole)
