It’s rare that an FPV camera works both as a low-light and daytime flying camera. You usually cannot have one with the other, but Caddx has made this possible with the Caddx Baby Ratel!
The Caddx Baby Ratel has superb night vision performance in addition to an excellent daytime image with ultra-low latency. Equipped with high quality 1/1.18″ Inch starlight HDR sensor, providing up to 0.0001 Sensitivity of lux. With the OSD menu, you can switch between PAL and NTSC video standards, or between 4:3 and 16:9 video formats. Ultra-low latency of 8ms means you feel locked in with your video.
The 1.88mm lens option gives you a large FOV (160°) to see all around you.
Features of Caddx Baby Ratel
- High quality 1/1.18″ Inch starlight HDR sensor
- OSD menu
- Switch between PAL and NTSC video standards or between 4:3 and 16:9 video formats
- Ultra-low latency of 8ms
- 1.8mm tarsier V2 HD Lens
Specification of Caddx Baby Ratel
- Image Sensor: 1/1.8″ Inch starlight HDR sensor
- Horizontal Resolution: 1200TVL
- TV System: NTSC & PAL (changeable)
- IMAGE: 16:9 & 4:3 (changeable)
- WDR: Super WDR (HDR)
- Min. Illumination: Starlight
- Lens: 1.8mm
- Synchronization: Internal
- Electronic Shutter: PAL: 1/50~100,000; NTSC: 1/60~100,000
- S/N Ratio: >60dB (AGC OFF)
- Video Output: CVBS
- Camera OSD: OSD
- DNR: 3-DNR
- LANGUAGE: ENG/FRANCE/RUS/SPA/PU/KOREA/CHN/JAPAN
- Day/Night: Auto/Color/B&W/EXT
- Dimensions: 14x14x19mm
- Wide Power Input: DC 3.3-5.5V
- Work Temperature: -20℃~+60℃
- Work Humidity: 20%~80%
- Weight: 4.6g (N.W.)
- 1 x Caddx Baby Ratel
- 1 x 5D-OSD Menu Board
- 1 x 14mm-19mm Case
- 1 x Warranty Card
- 1 x FPV Silicone Cable B
- 1 x Internal Hexagonal Wrench
- 8 x Screws
Need a micro version of Caddx’s ever-popular camera? Check out the Caddx Ratel 2 from drkstore.in!
Get more information regarding this product from Caddxfpv.
